FM200 Clean Agent Gas Fire Extinguisher 70L 90L 120L 150L 180L Fk-5112 Total Flooding Fire Suppression System For Server Room

FM200, also known as HFC-227ea, is a clean gas fire extinguishing agent commonly used in total flooding firefighting systems.
The FM200 system is designed to extinguish fires by rapidly reducing the oxygen concentration within the protected space to inhibit the combustion process. This fire suppression system is often used in areas where water-based fire suppression systems may not be effective or where the use of water may cause damage to sensitive equipment or valuable assets.

HFC-227ea: Refers to HFC-227ea as the main extinguishing agent, with automatic control system used in automatic fire extinguishing equipment.
At present, we have designed two types of appearance of cabinet and pipe network, and divided into a single bottle group, multi-bottle group has different size specifications, can be used for different occasions.

3. Effective on Class A, B, and C Fires:
FM200 is effective on a wide range of fires, including those involving ordinary combustibles
(Class A), flammable liquids (Class B), and electrical fires (Class C). It works by interrupting the combustion process without causing harm to electronic equipment.

Components of Pipe Network FM200 Fire Suppression Systems:

1. Storage cylinder: Cylinder, container valve (with pilot valve, pressure indicator), dip tube, etc.
2. High pressure hose: Connect cylinder valve and liquid checkvalve
3. Discharge Nozzle: Fitted at the end of pipe network to discharge fire suppressing agent
4. Control System: Control panel, smoke and heat detector, fire alarm, discharge indicator light, etc

1. FM200(HFC-227ea) Cylinder Specifications-4.2Mpa:

FM200(HFC-227ea) Cylinder Specifications-5.6Mpa:

2. FM200 Nozzle for Pipework Type---Female

HFC-227ea FM200 fire system devices are generally used in conjunction with fire detectors, fire alarm fire extinguishing controllers, emergency start/stop buttons, sound and light alarms, deflation indicators and other fire fighting equipment. When a fire occurs in the protection area, the temperature and smoke detectors will send out a fire signal.

After the logic analysis of the automatic fire alarm and extinguishing controller, it will send out a sound and light composite alarm signal, and at the same time send out a linkage command to turn off the linkage equipment.

After a delay time, a fire extinguishing command is issued, the solenoid valve driver is opened, the container valve is opened, the fire extinguishing agent is released, and the fire is extinguished; if the duty officer discovers a fire, he can press the emergency start button outside the protective area door to implement the fire extinguishing operation ; There is also a manual button on the solenoid valve driver, and mechanical emergency manual operation can also be used to extinguish fire in an emergency.

I. Single Bottle With Pilot Bottle or With Solenoid Valve

II. Multiple Bottle With Pilot Bottle or With Solenoid Valve

III. Multi-Room Distribution System with Pilot Bottle
