Hangzhou PRI-SAFETY Fire Technology Co., Ltd. is known as one of the most professional manufacturers and suppliers of various safety products in China. If the ce standard foam fire extinguisher wheeled dry powder fire fighting equipment meets your requirement, welcome to buy quality equipment made in China here from our factory. Our factory will offer you one stop service and one year warranty.
Foam wheeled fire extinguisher
1. Product description
■ ISO 9001 certified quality management system, CE approved
■ Suitable against class A and class B.
■ All fire extinguishers must be serviced in accordance with BS5306
■ Polyester powder external coating (Red, Cream).
■ Polyester powder Internal coating(Gray).
■ All fire extinguishers are tested no leakage.
■ Chemical Agent: AFFF3% Foam, Pressured with nitrogen gas.
■ Working Pressure: 15Bar. Test Pressure: 35Bar.
■ EN1866-1 Approved
2. Specification
Stored Type | External Type | ||||||
Capacity | 25L | 50L | 25L | 100L | 25L | 50L | 100L |
Item No. | PSE27-01 | PSE27-02 | PSE28-01 | PSE28-02 | PSE29-01 | PSE29-02 | PSE29-03 |
Out-dia.(mm) | 270 | 320 | 270 | 406 | 270 | 320 | 406 |
Cylinder Length (mm) | 625 | 875 | 625 | 1100 | 625 | 875 | 1100 |
Cylinder Weight (kg) | 20 | 32 | 20 | 50 | 20 | 32 | 50 |
Extinguisher Weight (kg) | 55 | 95 | 55 | 160 | 60 | 100 | 180 |
Volume(L) | 30 | 59 | 30 | 124 | 30 | 59 | 124 |
Filled Weight (kg) | 25 | 50 | 25 | 100 | 25 | 50 | 100 |
Temperature Range | 0+55℃ | 0+55℃ | 0+55℃ | 0+55℃ | 0+55℃ | 0+55℃ | 0+55℃ |
Working Pressure(bar) | 15 | 15 | 15 | 15 | -- | -- | -- |
Testing Pressure(bar) | 35 | 35 | 35 | 35 | 35 | 35 | 35 |
Min Wall-Thickness(mm) | 2.5 | 3.0 | 2.5 | 3.0 | 2.5 | 3.0 | 3.0 |
Material | HP295/ B440HP | HP295/ B440HP | HP295/ B440HP | HP295/ B440HP | HP295/ B440HP | HP295/ B440HP | HP295/ B490HP |
Fire Class | 55A 1BC | 55A 2BC | 55A 1BC | 55A 3BC | 55A 1BC | 55A 2BC | 55A 3BC |
Carton Size (cm) | 58x47x97 | 63x50x111 | 44x45x95 | 62x57x122 | 43x46x95 | 53x48x98 | 60x70x112 |
3.Production line
4.Certifications
5.Packing and shipping
