Products Description
FK-5-1-12 / Novec-1230 Clean Agent Total Flooding Fire Systems
When the control mode selection key on the automatic fire alarm and fire extinguishing controller is set to the "auto" position, the fire extinguishing system is under automatic control. When a fire occurs in the protection area, the temperature and smoke detectors will send out a fire signal through the automatic fire alarm and extinguishing control. After the logic analysis of the device, it sends out a combined sound and light alarm signal, and sends out a linkage command at the same time to close the linkage device. After a delay, a fire extinguishing command is issued, the starting valve is opened to release the starting gas and the starting gas is opened through the control gas pipeline valves and container valves release the fire extinguishing agent and implement fire extinguishing.
Three Types FK-5-1-12 FSS
FK-5-1-12 / Novec-1230 Total Flooding Fire System, FK-5-1-12 / Novec-1230 clean gas automatic fire suppression systems, FK-5-1-12 / Novec-1230 fire extinguishing system Cabinet Type FK-5-1-12 / Novec-1230 Fire Extinguisher
Products Features
--Very swift fire suppression.
--Reach extinguishing level ≤10s.
--Safe to people. People is safe when exposed at the FK5112 discharge level.
--Low extinguishing concentration. Nearly no obscure to vision in person evacuation.
--Easy to clean. No residue left, and minimize damage to sensitive equipment.
--Environment friendly. Zero ozone depletion potential and zero global warming potential.
--Sustainable technology providing an environmentally friendly solution.
--Simple installation, with small storage space.
Products Components
1. Components of Cabinet Type FK-5-1-12 / Novec-1230 Fire Suppression Systems
1. Storage cylinder: Cylinder, container valve (with solenoid valve, pressure indicator), dip tube, etc.
2. Discharge Nozzle: Fitted at the cabinet to discharge fire suppressing agent.
3. High Pressure Hose
4. Pressure Switch
5. Pressure Gauge
6. Cylinder Cabinet
8. Cylinder Clamp
9. Control System: Control panel, smoke and heat detector, fire alarm, discharge indicator light, etc.
2. Components of Pipe Network Pnematic Valve Type FK-5-1-12 / Novec-1230 Fire Suppression Systems
1. Storage cylinder: Cylinder, container valve (with pilot valve, pressure indicator), dip tube, etc.
2. Liquid check valve: Assure one way flow of fire suppression agent, to prevent backflow.
3. High pressure hose: Connect cylinder valve and liquid check valve .
4. Safety valve: Fitted on the manifold to relieve higher pressure.
5. Selection valve: Guide fire suppression agent into different distribution pipe network.
6. Starting gas bottle: Bottle, container valve, electromagnetic drive device, pressure gauge.
7. Gas check valve: Assure one way flow of starting gas, to prevent backflow.
8. Low leakage high sealing valve: For accumulated starting gas release so to avoid malfunction of system.
9. Discharge Nozzle: Fitted at the end of pipe network to discharge fire suppressing agent.
10. Control System: Control panel, smoke and heat detector, fire alarm, discharge indicator light, etc.
3. Components of Pipe Network Solenoid Valve Type FK-5-1-12 / Novec-1230 Fire Suppression Systems
Products Specification
Need Customized one-to-one according to the scene
The specific specifications need to be customized one-to-one according to the scene you use and the height and size of the site.
If you have any needs, please contact us and we will customize a solution for you. The above is the specification details of Cylinder Specification---4.2MPa/5.6MPa(Filling Pressure)
|
FK-5112 Cylinder Specification---4.2MPa/5.6MPa |
|||
|
No. |
Specification |
Technical Parameter |
|
|
1 |
Filling pressure |
4.2Mpa |
5.6Mpa |
|
2 |
Scale of Protective region for one zone |
Area：max single-zone is 800m² volume：max single-zone is 3600m³ |
|
|
3 |
Spraying time |
10s |
|
|
4 |
Filling density |
≤950kg/m3 |
≤1080kg/m3 |
|
5 |
Power |
DC24V/1.6A |
|
|
6 |
Nitrogen Pressure of Driving Device |
6.0±1.0Mpa(20℃) |
|
|
7 |
Condition of reserving room for container |
temperature: -10~50℃, relative humidity: ≤97% |
|
|
8 |
Max working pressure |
5.6Mpa |
8.0Mpa |
|
9 |
Min working pressure |
4.2Mpa |
5.6Mpa |
|
10 |
Capacity |
16/32/40/70/82.5/90/100/120/140/150/250/345/350/450/500 L |
|
Working Drawing
Products Process
Products Application
The FK-5112 Fire system is widely used in various scenarios, including but not limited to
computer rooms, data processing centers, semiconductor manufacturing facilities, industrial process control rooms, petrochemical facilities, chemical storage rooms, libraries and museums, critical military applications, Bank vaults, Libraries, Book stores, Electronic data processing, Telephone exchanges, Communication centers, Transformer and switch room, Control rooms, Test laboratories, Flammable liquid storage.
Packing & Delivery
Other related products
1. We also have FM200/HFC-227ea Total Flooding Fire System, FM200/HFC-227ea Fire Extinguishing system Pipe Network Type FM200/HFC-227ea Fire Extinguisher
FM200/HFC-227ea Total Flooding Fire System (Three Types)
Cabinet Type FM200/HFC-227ea Clean Agent Total Flooding Fire Systems
2. High Preesure Water Mist Fire Suppression System
High Preesure Water Mist Fire Suppression System
Pump Pressurized Type High Preesure Water Mist Fire Suppression System
A water mist system is a fire protection system which uses very fine water sprays (i.e. water mist). The small water droplets allow the water mist to control, suppress or extinguish fires by:
Cooling both the flame and surrounding gases by evaporation---Absorb Heat&Cooling
Displacing oxygen by evaporation---Isolate Oxygen
Attenuating radiant heat by the small droplets themselves---Isolate Heat
The effectiveness of a water mist system in fire suppression depends on its spray characteristics, which include the droplet size distribution, spray density and spray dynamics, with respect to the fire scenario, such as the shielding of the fuel, fire size and ventilation conditions.
So really high pressure system, specialized tubing or piping that's used for that. Now, there are differences between water mist systems and the droplet sizes that they produce, so typically the smaller the water droplet size the better it is at extinguishing a hot fire. Larger droplets can work faster on lower temperature fires, but they all work for the systems that they're approved for or listed for.
Cylinder Pressurized Type High Preesure Water Mist Fire Suppression System
A water mist system is a fire protection system which uses very fine water sprays (i.e. water mist). The small water droplets allow the water mist to control, suppress or extinguish fires by:
Cooling both the flame and surrounding gases by evaporation---Absorb Heat&Cooling
Displacing oxygen by evaporation---Isolate Oxygen
Attenuating radiant heat by the small droplets themselves---Isolate Heat
The effectiveness of a water mist system in fire suppression depends on its spray characteristics, which include the droplet size distribution, spray density and spray dynamics, with respect to the fire scenario, such as the shielding of the fuel, fire size and ventilation conditions.
So really high pressure system, specialized tubing or piping that's used for that. Now, there are differences between water mist systems and the droplet sizes that they produce, so typically the smaller the water droplet size the better it is at extinguishing a hot fire. Larger droplets can work faster on lower temperature fires, but they all work for the systems that they're approved for or listed for.
In a cylinder type water mist fire system, the water (or water mixed with an additive) is stored in pressurized cylinders rather than in a large water tank or being connected to a continuous water supply. These cylinders are typically filled with water and pressurized with a gas, such as nitrogen.
